The LR-1BS5 is a 2D plane-scanning lidar that scans the surrounding area on a single plane with the aid of an infrared invisible laser beam. The LR-1BS5 uses two dimensional polar coordinates to characterize the surrounding environment based on its measurement origin. With a scanning Angle range of 270°, the LR-1BS5 can detect and output the Angle, distance and signal strength information of the target, which is convenient for the SLAM system to better identify the target. The LR-1BS5 can be widely used in different industries such as robot navigation, obstacle avoidance, security monitoring, industrial automation, intelligent logistics and so on.

Ømain feature：

lApply to SLAM navigation and point cloud obstacle avoidance strategy,

lUsers can set the weak signal intensity of the value adjustment, dealing with differential usage scenarios,

lBuilt-in multilevel filter algorithm, the customer can be set up on demand, deal with the tail,

l0.225°Fixed angular resolution，

l±0.5° precision level Angle, to ensure that the horizontal distance,

l40k/sPrecision level Angle, to ensure that the horizontal distance,

lCertification: FCC，EMC，CE，RoHS，REACH，FDA,

lProtection grade：IP66
